AMT 4S13XHR 4 Inch Trash Pump, 13 HP, Honda GX390 Motor

AMT 4S13XHR 4 Inch Trash Pump, 13 HP, Honda GX390 Motor

IPT Portable High Volume, Self-priming Centrifugal Trash pumps include easy cleanout with replaceable cast iron impeller and volute that resist abrasion/wear. All pumps feature aluminum housing, cast iron wearparts, built-in check valve, suction strainer and heavy duty steel roll frame. Heavy duty cast iron flanges with male NPT threads that rotates in 90° increments. Easy access fill plug on discharge port.

Features:

• Cast Aluminum with Internal Cast Iron Wearparts for Durability

• Silicon Carbide/Viton® Mechanical Seal

• EPDM/EPR O-Rings Standard with Optional Viton®

• 3˝ or 4˝ Removable Male NPT Suction and Discharge Ports

• Discharge Rotates in 90° Increments

• Engine Options: Honda, LCT Storm Force Gasoline or Hatz Diesel Engines

• Maximum Solids Handling up to 2˝

• Maximum Flow up to 530 GPM

• Maximum Head up to 112 Ft.

• Self-Priming to 26 Ft.

• Wheel Kit Optional

Specifications:

• Motor: Honda GX390

• Motor HP: 13 HP
• Pump Body: Cast Aluminum
• Suction/Discharge: 4" NPT
• Seal Material: Viton

• Max Flow Rate: 530 GPM
• Max Working Pressure: 78 PSI
• Max Temperature: 160° F
• Tank Size: 1.6 Gallons / 6.1 Liters
• Run Time: 2.5 Hours



Resources:

Pump Datasheet

Owners Manual
