PRMFiltration Guardian 1 Inch PVC Suction Hose, 100 Ft. Length

STANDARD DUTY PVC SUCTION HOSE - 1 INCH

PVC suction hose for drain lines, irrigation, pumps, dewatering and standard duty water suction.

Constructed of PVC tube with rigid PVC helix.

Service Temperature: -4°F to 150°F

2.76" Bend Radius

Specifications:

Inside Diameter	Outside Diameter	Working Pressure	Vacuum Rating	Weight (lbs/ft.)
1 Inch	1.26 Inch	75 psi at 68°F 50 psi at 104°F	29 in. Hg at 68°F	.26
1-1/4 Inch	1.56 Inch	75 psi at 68°F 50 psi at 104°F	29 in. Hg at 68°F	.35
1-1/2 Inch	1.83 Inch	75 psi at 68°F 50 psi at 104°F	29 in. Hg at 68°F	.48
2 Inch	2.32 Inch	75 psi at 68°F 50 psi at 104°F	29 in. Hg at 68°F	.66



Standard bundle length is 100 ft, but PRM can provided a custom length of hose in 10 foot increments, Contact PRM for questions: 888-873-2848.
