PRM Pneumatically Actuated Direct Acting uPVC True Union Ball Valve

PRM pneumatically actuated uPVC ball valves are designed with uPVC materials which is more chemically resistant than standard PVC.  Unplasticized PVC provides longer life than typical PVC valves in applications where chemical softening or leaching resistance is needed.  Standard O-rings on the valve assembly and the stem are Viton to ensure that degradation of the seals does not cause leaks.

Pneumatically Actuated uPVC Ball Valve Datasheet

FEATURES:

• Direct Acting, On-Off Actuator
• True Union Ball Valve, directional flow
• Connections: ANSI (Socket)
• Full Port for unrestricted flow
• PTFE Seat for lower torque and extended life
• Valve Pressure Rating: 150 PSI
• Valve Temperature Range: 32° to 130°F
• Air Connections: 1/4 Inch

Includes:

• Solenoid Control—110-120 VAC

Available Option:

• POO/POC Limit Switch

Materials:
Valve Body: uPVC (gray)
Stem: PPO
Seat: PTFE
O-Rings: Viton

Typical Applications:
Remediation or process water with dissolved solvents or petroleum compounds
Landfill Leachate Applications
Process Liquid Applications where a higher degree of valve durability is needed.
