RKI Instruments GX-6100 Multigas Detector - 72-61AXXT-C

RKI Instruments GX-6100 Multigas Detector - 72-61AXXT-C

The GX-6100 is a powerful hand-held instrument capable of simultaneously monitoring up to 6 gases. In addition to the standard 4 confined space gases which include combustibles, O2, CO, & H2S, the GX-6100 has 2 additional smart channels that accept PID, PPM, IR or super toxic sensors. The updated GX-6100 can measure combustible gases in PPM range and %volume in the same monitor.



Features:

• Smallest 6 gas sample draw detector
• New 4-gas sensors with up to 3-year warranty
• 2 Interchangeable smart sensor slots
• TC sensor for %volume measurement of combustibles
• New ppm MOS CH4 and ppm MOS i-C4H10 sensors
• 4 PID options: 10.6 (2 ranges) eV, 10.0 eV, and 11.7 eV lamps
• Supports dual PID sensors
• PID library of over 600 VOCs
• Rapid sharing of emergency alerts via Bluetooth®
• Benzene specific version
• PPM Leak Check mode
• LEL sensor protection mode
• Man-down alarm
• Panic alarm
• Auto display rotation
• Peak-bar display
• LED Light source
• Internal sample pump
• Light weight, small, rugged IP-67 design
• Interchangeable battery packs (Li-ion / alkaline)
• Operates up to 28 hours on Li-ion battery pack, 8 hours operation with alkaline pack
• Field replaceable sensors, batteries, filters and pump
• Intrinsically safe ATEX / IECEx / cCSAus (pending)



Applications:

• Confined Space Entry
• Hazmat Response Teams
• Arson Investigation
• Remediation Site
• Perimeter Monitoring
• Leak Detection
• Landfill Monitoring
• Winery Tank Entry

Specifications:

Common Specifications
Alarm Types	Gas alarm	Man-down	Trouble
	Low and high adjustable	1st – self reset   2nd – latching	Low flow   Sensor connection Low battery Circuit error Calibration failure
Sample Method	Sample draw pump, flow rate 0.45 LPM, 100 foot sample range
Display	Digital LCD, autobacklight, peak bar display, auto display rotation, and customize order of gases
Communication	Bluetooth, IrDA
Audible Alarm	95 dB at 1 ft.
Languages	English, Japanese, French, Spanish, Portuguese, Italian, German, Russian, Korean, Chinese (simplified), Chinese (traditional), Vietnamese, Slovak, Czech, Turkish, Polish
Continuous Operation	28 hours on Lithium-ion battery pack. Complete recharge in 6 hours.   8 hours Alkaline battery pack (3 AA size in each pack)
Operating Temp. & Humidity	-4°F to 122°F (-20°C ~ +50℃), 0- 95% RH non condensing
Dimensions	2.6” W x 7.9” H x 2.2” D (H200 x W68 x D56 mm) 17.6 ounce (500g) with lithium battery pack16 ounces with alkaline batteries (450g)
Case Material	Dust and water resistant with IP-67 approval (exclude sample hose and probe)
Safety Design /   Approvals	Explosion proof: IECEx , ATEX , TIIS , cCSAus (pending)   Explosion class :Ex ia IIC T4 Ga Others: CE Marking
Standard Features	2 Smart sensors slots auto recognize sensor changes Panic alarm and man down alarm Library of over 600 VOC’s User defined VOC list. Up to 30 frequently used Recent VOC list for last 8 selected gases Pump and circuit status indicators User & station ID selection menu Datalogging (interval, alarm trend, station and user ID) Snap logging – on demand data logging Demand zero / Auto zero BUMP and CAL expiration alarm Flashlight LEL sensor protection mode
Optional Accessories	• SDM-6100 calibration station
Warranty	Three years material (including  R sensors) and workmanship. 2 years for IR sensors and ESS (except Cl2), One year for TE, Cl2 and PID sensors (Two months for 11.7 eV lamp)





Resources:

Datasheet

Operations Manual
