Teltonika TSW114 Gigabit Unmanaged 5 Port Ethernet Switch

Teltonika TSW114 Gigabit DIN Rail Ethernet Switch 5 Port Unmanaged

TSW114 is an affordable way to simplify your connectivity with its plug and play nature and 5 x Gigabit Ethernet ports that provide stable and reliable connectivity for high-bandwidth solutions. The Ethernet switch has front-facing ports and an integrated DIN rail bracket to enable easy installation across many industrial environments - especially control cabinets.



Features:

• Integrated DIN rail bracket and front-facing ports
• 5 x Gigabit Ethernet ports with speeds of up to 1000 Mbps
• Rugged anodized aluminum housing that fits in your pocket

Specifications:

• Power supply: 2-pin industrial DC power socket, 9 - 30 VDC
• Power consumption: Idle: 0.3 W / Max: 2.3 W
• Status LEDs" 1 x Power LED, 10 x LAN status LEDs
• Ethernet" 5 x RJ45 ports, 10/100/1000 Mbps
• Ingress protection rating: IP30
• Operating temperature: -40 °C to 75 °C
• Housing" Anodized aluminum housing and panels
• Dimensions: 113.1 x 27.4 x 80.5 mm
• Weight: 174 g
• Installation: Integrated DIN rail bracket, wall mounting (additional kit needed), flat surface placement



Resources:

Brochure

Datasheet
