PRM 1-1/2 HP Centrifugal Pump, 115V/230V, Single Phase

1-1/2 HP Centrifugal Pump - 115V/230V - Single Phase

Description

• Great for underground sprinkler systems, drawing water from wells, lakes and ponds, or any application where greater water volume is needed.


Features and Benefits

• Durable cast iron volute

• Reinforced impeller and diffuser for long-life

• Built-in automatic thermal overload protector

• Dual voltage (115/230V) high efficiency square, flanged motor, factory set for 115V

• 2” NPT suction with 1-1/2” NPT discharge






Model	HP	Voltage	Amp	Discharge NPT
PRMPUMPCICP1501PH	1-1/2	115/230V	18.0/9.0A	1-1/2 Inch
PRMPUMPCICP2003PH	2	230V	9.0A	1-1/2 Inch



GPH of water @Total Ft. of Head for PRMPUMPCICP1501PH

					Max. Head Ft.
20 ft.	40 ft.	60 ft.	80 ft.	100 ft.	108 ft.
4250 gph	3750 gph	3150 gph	2400 gph	950 gph	-





Flow Curve

User Manual
