PRM #2 316L Stainless Steel 3 Bag Multi-Filter Housing, 2 Inch Tri-Clamp In/Out-150 psi

PRM #2 316L Stainless Steel 3 Bag Multi-Filter Housing, 2 Inch Tri-Clamp In/Out-150 psi


PRM MULTI BAG FILTER HOUSING, 316L STAINLESS STEEL 2 INCH TRI-CLAMP INLET/OUTLET

Multi Bag Filter Housings for industrial filtration needs.

#2 Standard Industrial Size Multi-Bag (3 bag) Housing, 316L Stainless Steel.

Features:

  • 316L Stainless Steel Construction,
     Electropolish Finish
  • Uses Trade Size # 2 Liquid Filter Bags
  • 3 Bag Housing: 2” Tri-Clamp Inlet and Outlet Connections
  • 1.5" Tri-Clamp Vent Port on Lid
  • EPDM Food Grade O-rings
  • 150 psi Maximum Working Pressure
  • Operating Temperature: normal range of 50°F - 90°F. Variance outside of this temperature range will affect maximum operating pressure rating. Liquids operating at elevated temperatures pose a risk of burns.
  • Stainless Steel Strainer Baskets and Internal Bag Support Rack
  • Quick Opening Bolt Top
  • Head loss is negligible with an empty housing and clean bag(s)
  • Approx. Shipping Weight: 315 lbs.

BFHBFM3CTRI316LSSXV2 Datasheet

BFHBFM3CTRI316LSSXV2 Drawing

Item is Oversize/Overweight and must be shipped Motor freight.



$2,800.00

Original: $7,999.99

-65%
PRM #2 316L Stainless Steel 3 Bag Multi-Filter Housing, 2 Inch Tri-Clamp In/Out-150 psi—

$7,999.99

$2,800.00
Product image 1
Product image 2
Product image 3
Product image 4

Description


PRM MULTI BAG FILTER HOUSING, 316L STAINLESS STEEL 2 INCH TRI-CLAMP INLET/OUTLET

Multi Bag Filter Housings for industrial filtration needs.

#2 Standard Industrial Size Multi-Bag (3 bag) Housing, 316L Stainless Steel.

Features:

  • 316L Stainless Steel Construction,
     Electropolish Finish
  • Uses Trade Size # 2 Liquid Filter Bags
  • 3 Bag Housing: 2” Tri-Clamp Inlet and Outlet Connections
  • 1.5" Tri-Clamp Vent Port on Lid
  • EPDM Food Grade O-rings
  • 150 psi Maximum Working Pressure
  • Operating Temperature: normal range of 50°F - 90°F. Variance outside of this temperature range will affect maximum operating pressure rating. Liquids operating at elevated temperatures pose a risk of burns.
  • Stainless Steel Strainer Baskets and Internal Bag Support Rack
  • Quick Opening Bolt Top
  • Head loss is negligible with an empty housing and clean bag(s)
  • Approx. Shipping Weight: 315 lbs.

BFHBFM3CTRI316LSSXV2 Datasheet

BFHBFM3CTRI316LSSXV2 Drawing

Item is Oversize/Overweight and must be shipped Motor freight.
