PRM 1 Inch NPT Stainless Steel Multi-Jet Totalizing Water Meter
STAINLESS STEEL PRM MULTI-JET WATER METERS
Stainless Steel Water Meters for indicating flow totalization of water. Stainless Steel offers additional corrosion resistance when totalizing liquids with corrosive or chemical elements. Designed for long service life and maintenance-free operation, built for harsh conditions with hydrocarbon resistant Viton® seals.
Features:
Sealed Dry Dial for Clear Readings
Internal Strainer to Protect Meter from Particulate Damage
Specifications:
Class: B
Accuracy: Transitional Flow: ± 5%
Nominal Flow: ± 2%
Maximum Water Temperature: 104°F
Maximum Water Pressure: 150 psi
Mounting Orientation: Horizontal
Materials:
Body: 304 Stainless Steel, polyethylene
Couplings: 304 Stainless Steel
Measuring Chamber: Polyethylene
Seals: Viton
Mounting Orientation: Horizontal
PRM Stainless Steel water meters are not NSF 61 certified. Please check local water regulations to choose the correct meter for your application. California, Vermont, Maryland and Louisiana state laws require that all the water meters used be NSF 61 certified.
| PRM Part # | Size | Length (in.) (w/NPTadapters) |
Height (in.) | Weight | Nominal Flow (GPM) |
| WM050SSVX | 1/2 Inch | 10.5 | 4.75 | 3 lbs. | 1-10 |
| WM075SSVX | 3/4 Inch | 12 | 4.75 | 3.5 lbs. | 1-20 |
| WM100SSVX | 1 Inch | 13 |
4.75 | 5.5 lbs. | 2-30 |
| WM125SSVX | 1-1/4 Inch | 15.5 | 5 | 6 lbs. | 3-50 |
| WM200SSVX | 2 Inch NPT | 18 | 6.5 | 15lbs. | 5-125 |
| WM200FLSSVX | 2 Inch Flange | 10.5 | 6.5 | 25 lbs. | 5-125 |
