Schulz Compressors SRP Compact Series Rotary Screw Air Compressor
Schulz Compressors SRP Compact Series Rotary Screw Air Compressor
Please refer to the table below for specs.
The Schulz Compressors SRP Rotary Screw Air Compressor features a tank mounted solution with an ASME tank. Compressors with 25 horsepower or higher include TEFC motors, and the unit is air cooled.
Features:
- Tank mount
- 60 to 120gal tank
- Horizontal orientation
- 7.5 to 40 HP
- 25 to 150 CFM
- 125 PSIG pressure rating
- Voltage options:
- 230/1/60
- 208-230/3/60
- 460/3/60
- 1/2 to 1" discharge connection
| Item # | Model |
HP | Voltage | PSI | CFM | Tank Style | gal | lbs. |
|
970.3890-0 |
SRP-3008 COMPACT-1 |
7.5 |
230/1 |
125 |
27 |
Horizontal | 60 | 443 |
| 970.3891-0 | SRP-3008 COMPACT-3 208V | 7.5 | 208-230/3 | 125 |
27 | Horizontal | 60 | 443 |
| 970.3891-460 | SRP-3008 COMPACT-3 460V | 7.5 | 460/3 | 125 | 27 | Horizontal | 60 | 443 |
| 970.3454-0/F |
SRP-3015 COMPACT-II 208V |
15 | 208-230/3 | 125 | 51 | Horizontal | 60 | 462 |
| 970.3454-460 | SRP-3015 COMPACT-II 460V | 15 | 460/3 | 125 | 51 | Horizontal | 60 | 462 |
| 970.2840-S | SRP-3025 COMPACT 208V | 25 | 208-230/3 | 125 | 89 | Horizontal | 80 |
850 |
| 970.2840-1 | SRP-3025 COMPACT 460V | 25 | 460/3 | 125 |
89 | Horizontal | 80 |
850 |
|
970.3233-S |
SRP-3040 COMPACT 208V |
40 |
208-230/3 | 125 | 120 |
Horizontal | 120 | 980 |
|
970.3233-460 |
SRP-3040 COMPACT 460V |
40 | 460/3 |
125 | 120 | Horizontal | 120 | 980 |
Select HP
From $2,961.70
Original: $8,462.00
-65%Schulz Compressors SRP Compact Series Rotary Screw Air Compressor—
$8,462.00
$2,961.70
